Name: FLUKE 810 Handheld Vibration Tester
Brand: FLUKE
SKU: 1686
Availability: InStock

Description

FLUKE 810 Handheld Vibration Tester

Key features

On-board identification and location of the most common mechanical faults (bearings, misalignment, unbalance, looseness) focus maintenance efforts on root cause, reducing unplanned downtime
Overall vibration level allows you to quickly assess overall machine health directly from the diagnosis screen
Fault severity scale with four severity levels helps you prioritize maintenance work
Repair recommendations advise technicians on corrective action
Detailed diagnostic reports and spectral diagrams help confirm data quality, and narrow down the root cause of failures
On-board context sensitive help provides real-time tips and guidance to new users

General Specifications
Dimensions (H x D x W)	18.56 x 7.00 x 26.72 cm (7.30 x 2.76 x 10.52 in)
Weight (With Battery)	1.9 kg (4.2 lb)
Display	¼ VGA, 320 × 240 Color (5.7 inch diagonal) TFT LCD with LED backlight
Input/Output Connections	Triaxial sensor connection	4 pin M12 connector
	Single axis sensor connection	BNC connector
	Tachometer Connection	Mini DIN 6 pin connector
	PC Connection	Mini ‘B’ USB (2.0) connector
Battery	Battery type	Lithium-ion, 14.8 V, 2.55 Ah
	Battery charging time	Three hours
	Battery discharge time	Eight hours (under normal conditions)
AC Adapter	Input voltage	100 VAC to 240 VAC
AC Adapter	Input frequency	50/60 Hz
Operating System	WinCE 6.0 Core
Language Support	English, French, German, Italian, Japanese, Portuguese, Simplified Chinese, Spanish
Warranty	Three-years
